W1 Drill Rod
W1 Drill Rod is a water hardening tool steel rod containing a higher amount of carbon. It is ductile, easy to work, and can be easily formed. It is ground to tight tolerance diameter and has good strength. It is a cost-effective option. It has excellent wear resistance and decarburization resistance properties. Due to its physical and mechanical properties, it is considered suitable for various applications such as
- Dies
- Punches
- Taps
- Stamps
- Knives
- Slitters and cutters
- Shafts
- Machine parts
- Tools
- Chisels and many more.
We ensure good quality products at market competitive prices which can be ordered easily. W1 Drill Rod is available in huge stocks in different sizes at Metalsnet.
Specifications:
W1 Drill Rod, ASTM A686, AISI W1
Chemical Composition
Element | Percentage |
Carbon, C | 0.70-1.50% |
Manganese, Mn | 0.10-0.40% |
Tungsten, W | 0.15% |
Silicon, Si | 0.10-0.40% |
Chromium, Cr | 0.15% |
Molybdenum, Mo | 0.10% |
Vanadium, V | 0.10% |
Nickel, Ni | 0.20% |
Copper, Cu | 0.20% |
Mechanical Properties
Tensile Strength, Ultimate | 244000 psi |
Tensile Strength, Yield | 218000 psi |
Machinability | 100% |
Brinell Hardness | 498 |
Melting Point | 2615?F |
Density | 7.83 g/cm? |
Physical Characteristics
Machinability | Excellent |
Weldability | Good |
Strength | Good |
Corrosion Resistance | Fair |
Wear Resistance | Good |
*Data provided for the purpose of reference only.
